The Wireless and Long Distance Communication Laboratory includes in its structures equipment and facilities regarding a main laboratory of the School Electrical and Computer Engineering. An integral facility of the laboratory is an anechoic chamber of 7mx4mx3m dimensions and operating frequency range between 80MHz and 18GHz. The Anechoic chamber is surrounded by a Control Room, along with an Amplifier Room. The Control room includes instruments for the measurement of the signals that are driven out of the chamber. On the other hand, in the Amplifier room takes place the amplification of the signals that are driven inside the chamber.

Following, there is a list of the major equipment of the WLDCL:

Electrometrics 6961
Antenna
Linearly polarized antenna capable of operating as either a transmitting or receiving antenna. Exhibiting highly efficient performance characteristics for a broadband antenna. Frequency Range: 1 – 18 GHz Average VSWR: <1.5:1 Output Connector: Type N, female

Agilent E4403B
Spectrum Analyzer
9kHz to 3.0 GHz 1.1 dB overall amplitude accuracy 100 Hz to 5 MHz RBW, 100 Hz to 300 Hz optional +7.5 dBm TOI Narrow resolution bandwidth, 8590 series code compatibility, or 50 ohm tracking generator Agilent's PowerSuite one-button power measurements included as standard SCPI programming and IVI COM driver support Large, high-resolution, color display

Avionics IFR 2031
Signal Generator
2031: 10 kHz to 2.7 GHz 0.1 Hz resolution -144 to +13 dBm, 0.1 dB resolution 0.1 Hz to 500 kHz modulation oscillator Optional second internal modulation oscillator FM, Wideband FM, Phase, AM Optional pulse modulation Single, dual, composite and dual composite modulation modes GPIB (IEEE-488.2)

Electro-metrics EM-6917C-1
Biconical Antenna
Frequency Range: 30 MHz -1 GHz Impedance, nominal: 50 Ohms, nominal VSWR: <2.0:1, typical Power:1000 W, peak Connector: Type N, female

Schaffner SMR4503
EMI Measuring Receiver
Frequency range: 9 kHz -2.75 GHz Resolution: 100 Hz (1 kHz at IF-bandwidth 1 MHz) Accuracy: < 1 x 10-6 ± 1 Hz

Agilent N5181A MXG
RF Analog Signal Generator
100 kHz to 1, 3 or 6 GHz +23 dBm output power @ 1 GHz ² -121 dBc/Hz (typ) phase noise at 1 GHz and 20 kHz offset ²1/2 ms switching speed in SPI mode- ²900 μs simultaneous frequency and amplitude switching in list mode !M, FM, ØM, and pulse modulation Digital step and list sweep with simultaneous switching of frequency and power 100BaseT LAN, USB 2.0 and GPIB LXI class-B compliant SCPI and IVI-COM drivers

Agilent HP 8593A
Spectrum Analyzer
Frequency 9 kHz -22 GHz ,26.5 GHz with option 026 Span 10 kHz -19.25 GHz Sweep Time 20 ms 100 s Minimum Single-Side-Band Noise -95 dBc/Hz Maximum Amplitude Uncertainty 3 % Amplitue Range:-114 dBm to +30 dBm User memory: 32-plus Kbytes Internal preselector Frequency accuracy: 7.5 ppm

HP / Agilent 8656B
RF Signal Generator
100 kHz up to 2060 MHz Electronic attenuator on HP 8657A ± 1/0 d level accuracy (typically ± 0/5 d on HP 8657!) 50 Ω reverse power protection on HP 8657!/ AM, FM, and optional pulse modulation

Agilent HP 54645D
Digital Oscilloscope
100-MHz scope with 200 MSa/s 1 MB of memory per scope channel 16 logic timing channels with 400 MSa/s on 8 Channels, 200 MSa/s on 16 Channels 2 MB of memory per logic channel Agilent MegaZoom technology allows deep memory capture and a responsive display Simple easy-to-use controls Powerful triggering

PowerBright ERP2300-12
Power Inverter
Power Modified Sine Wave Inverter, 2300 220 Volt 50Hz AC Output 12 volt Cigarette Lighter Plug Built-in Cooling Fan Overload Indicator Provides 19.2 Amps Overload Indicator 11.5 x 7.5 x 2.75

Agilent N5182A MXG
RF Vector Signal Generator
100 kHz to 3 or 6 GHz >+23 dBm up to 3 GHz using a highly-reliable, fast-switching electronic attenuator W-DM! dynamic range. ²-73 dBc at +5 dBm output power ²900 μs simultaneous frequency, amplitude, and waveform switching in list mode !M, FM, øM, and pulse ASK, FSK, MSK, PSK, QAM Digital step and list sweep with simultaneous switching of frequency, power, and waveform 100 MHz internal I/Q baseband generator with real-time equalization for excellent EVM performance 100BaseT LAN, LXI class-B, USB 2.0, and GPIB SCPI and IVI-COM drivers

Promax TV EXPLORER II+
DVB-T Receiver and Analyzer
Coverage of satellite DVB-S and 8PSK, cable, Moblie, and analog television. Tuning by channel and frequency (IF or direct in the case of satellite) Automatic Channel search with the possibility to create channel plans for each new session. Fully automatic identification of digital & analog signals. Constellation Diagramming Capable of creating and comparing 'stored sessions' to decrease measuring times. Multi-standard analog measurements: Level, Video-Audio, C/N. Digital measurements: Power, C/N, Channel Identification. COFDM 2k/8k: MER, VBER, CBER, Noise margins QPSK: CBER, VBER, MER, Noise margins DVB-H: MER, CBER, VBER, Noise margins 8PSK: MER, CBER, LBER QAM 16/32/64/128/256: BER, MER. Simultaneous display of all the measurements and main associated parameters. MPEG-2 and MPEG-4 decoding. Transflective 6.5" (16:9 aspect ratio) LCD screen PKTools Software included Large Storage capacity TV EXPLORER II+: 1GB

Memsic IRIS-XM2110 (20 items)
2.4 GHz Mote module used for enabling low-power, wireless sensor networks
 2.4 GHz IEEE 802.15.4, Tiny  Wireless Measurement System  Designed Specifically for Deeply Embedded Sensor Networks  250 kbps, High Data Rate Radio  Wireless Communications with Every Node as Router Capability  Expansion Connector for Light, Temperature, RH, Barometric  Pressure, Acceleration/Seismic, Acoustic, Magnetic and other MEMSIC Sensor Boards  Program Flash Memory 128K bytes  Measurement (Serial) Flash 512K bytes  RAM 8K bytes  Configuration EEPROM 4K bytes  Serial Communications UART

Memsic MIBS20 (10 items)
USB Interface Board for WSN motes (Gateway and Programming)
 Base Station for Wireless Sensor Networks  USB Port Programming for IRIS/MICAz/MICA2 Hardware Platforms  Supports JTAG code debugging  USB Bus Power

Memsic MDA100 (20 items)
Sensor and Data Acquisition Boards
 Light and Temperature Sensor  UART connectivity

Electrometrics EM-6924
Antenna, Tunable Dipole Set
 Frequency Range (calibrated): 28-1000 MHz  EM-6923: 28 65 MHz  EM-6925: 65 180 MHz  EM-6926: 180 -400 MHz  EM-6927: 400 -1000 MHz  Input Impedance: 50 Ohms  Connector: Type BNC (Type N optional)  VSWR: Typically less than 1.6:1  Balun Loss: 0.5 dB maximum  Maximum Continuous Power: 20 W

HP 8714C
RF Network Analyzer
 300kHz-3GHz  Integrated transmission/reflection test set with narrowband and broadband detection  "Real time" sweep speed (50 ms/sweep), synthesized 1 Hz resolution source, and 100 dB of system dynamic range  Internal 3.5-inch disk drive (LIF/DOS formats) and VGA interface  Internal Agilent Instrument BASIC (IBASIC) capability  TCP/IP-compliant Ethertwist LAN interface option  AM delay and fault location/SRL options

TTI CPX200 Dual
Power Supplier
 Dual isolated outputs, 175 watts each  PowerFlex design gives variable voltage & current combinations within a maximum power range.  Higher current capability at lower voltages  Variable OVP trips  Precision control & metering  Selectable remote sense terminals  Compact half-rack 3U case size

HP 8559A
Spectrum Analyzer
 0.01 to 21 GHz spectrum analyzer plug-in  Direct plotter control  Display annotation and storage accessorles  Digital display with trace arithmetic  Resolution bandwidths from 1 kHz to 3 MHz  Absolute amplitude calibration in all bands

Schaffner EMC-20
E-field Probe
Frequency range 100 kHz to 3 GHz Meas. range 0.6 bis 800 V/m, 0.0001 to 170 mW/m2 Special features Automatic zero alignment, averaging (time), averaging (spatial) and data memory Display units mW/cm2, W/m2, V/m, A/m

Anritsu MS2721A
Handheld Spectrum Analyzer
The MS2721A was the first fully-functional handheld spectrum analyzer designed to conduct highly accurate analysis on the new wave of wireless LAN and cellular signals, including 802.11a, 3G, ultra -wideband, WiMAX, and wireless medical patient monitoring s ystems. The MS2721A was replaced with model MS2721B.

Schaffner Chase NFPS1
Near Field Probe Set

Aaronia AG HYPERLOG 4060
Antenna
 Design: Logarithmic-periodic  Frequency range: 400MHz-6GHz  Max. transmission power: 100 W CW  (400MHz)  Nominal impedance: 50 Ohm  VSWR (typ.): <1:2  Gain (typ.): 5dBi  Antenna factor: 20-40dB/m  Calibration points: 561 (10MHz steps)  RF connection: SMA socket (18GHz) or N  socket using an adapter  Dimensions (L/W/D): (590x360x30) mm  Weight: 1000gr

Aaronia BiocoLOG 20300
Antenna
 Only a single emc antenna for the complete frequency range from 20MHz up to 3GHz  Optimal for usage with spectrum analysers for EMC measurement  Suitable for mobile use  Robust design  Small weight and dimensions

Euroshield MF130D
RF Leak Detector / Attenuation Meter

Schaffner BILOG CBL6141A
Antenna
 frequency Range 30MHz 2GHz  impedance 50Ω  Connector: N-type  VSWR: Average 2:1  max transmit power: 300W  size (LxHxW cm): 135x97x41  weight: 3.5kg

Agilent E4418B EPM Series
Single-Channel Power Meter
 Fast measurement speed (up to 200 readings per second, over the GPIB, with E-series sensors)  Speed improvement of x2 using the 8480 series power sensor (compared to the 437B)  No range-switching delays with 8480 series sensors, and only one fast-range switch point with E-series sensors  Code compatibility with 437B and 436A power meters  GPIB and RS232 connector for remote control of all functions

Agilent 34401A
Digital Multimeter
 6½ digit resolution  12 measurement functions, plus limit testing, ratio and min/max average  Basic accuracy: 0.0035% DC, 0.06% AC  1000 V max input

Agilent 33220A
Function / Arbitrary Waveform Generator, 20 MHz
 20 MHz sine and square waveforms  Ramp, triangle, noise, pulse generation with variable edge, and DC waveforms  14-bit, 50 MSa/s, 64 Kpoint arbitrary waveforms  AM, FM, PM, FSK, and PWM Modulation, Linear & logarithmic sweeps and burst all standard

EXTECH Instruments 382270: Quad Output DC Power Supply
4-in-1 DC Power Supply
 Two fully adjustable supplies combined with two auxiliary outputs  Two 0 to 30V/0 to 5A outputs with selectable Constant Voltage and Constant Current modes  Two auxiliary outputs with fixed current of 3 to 6.5V/3A and 8 to 15V/1A

TTi TGR1 040
1GHz Synthesised RF Generator
 10MHz to 1000MHz frequency range  1kHz setability, +/-2ppm frequency stability  -127dBm to +7dBm amplitude, 0.1dB steps  FM modulation, internal or external
